hagercad software Take the low-voltage distribution planning to the next level



hagercad software Take the low-voltage distribution planning to the next level



Automatically better

01

Easily create and share your project

02

Quickly generate circuit diagrams

03

Greater accuracy for cabinets calculations

04

Automatic power loss and heat calculation feature

05

Simply generate your terminal plan

06

User-friendly function for device labels

07

Up-to-date documentation and operating instructions

New features

Version 5.5

Catalogue

  • Explore new solutions…h3+ MCCBs now included
  • Work efficiently with our newly improved interface: easier to view and select accessories with detailed information

Project Explorer

  • Work with peace of mind: be assured that your projects are save even while converting from one version to another
  • Share your project: send with or without quotation depending on your recipients

Project Editor

  • Save time and design faster: create & save templates of panel boards design consisting of your most common drawing layout, schematic, bill of material etc

Bill of material

  • Save time and stay prepared: with effective organisation of bill of material by enclosure and by functional units

Wiring diagram

  • Save time: modify similar products at once
  • Save time and change attributes of a symbol simply by double click
  • More possibilities: choose from power supply combinations
  • Save time: have automatic default values prefilled according to the type of power supply selected (for e.g. Ik1, 3 & Ukr)
  • Detailed information: display with or without terminal block on incoming connections (Direct or on terminals...)

Layout

  • More customizing possibilities: automatic cabinet dimension selection, choice of layers when creating graphical entities
  • More display options: technical summary as a drawing, electrical structure in project warehouse
  • Work efficiently: devices are oriented automatically according to the equipment kits selected

Quotation

  • Save time and stay prepared: with effective organisation of quotation by enclosure and by functional units
  • Select desired information to export to excel file

Printing

  • Save time and define default set of documents to print based on your customer needs
  • Optimized pdf files for easy transfer

Ask for a training

Contact your closest partner

  • Our experts will deliver you all relevant knowledge on hagercad to get straight to work with zero fuss.
  • Click here to contact your local partner and plan your next training session.
  • During the training session, you'll receive a 30-day trial full version of the software.
  • After 30 days, login to myHager to generate your key activation code for unrestricted access to hagercad.

FAQ

What is the latest hagercad software version?

hagercad 5.5 is the latest version available.

How can I get the software?

Contact your closest Hager partner . We recommend all our customers to attend a training session about the software in order to experience all the latest features.

Do I need a license in order to use the software?

Without activating your license, you'll be able to use full version of hagercad software during a 30-day trial period. After this duration, login to myHager to generate your key activation code for unrestricted access to hagercad.

I want to update my software version. Will my license be maintained if I install the new version on my computer?

Yes, your license will be saved under your myHager profile.

Can I download the new version of hagercad online?

We recommend all our customers to attend a training with our specialists. The software is delivered to all participants during the training sessions. Contact your closest Hager partner and register to the next training session.

How to upgrade to the latest version of the software?

Once you have the download link, uninstall the older version and install the new version which will automatically retain your settings.

What will happen to my saved projects when I update to the latest version?

Your saved projects will automatically be retained with the new update along with the personalisation in settings.

I need help more information about the software, who should I contact?

Contact your closest Hager partner.

How much does the hagercad software costs?

hagercad software is free of charge, after a 30-day trial period you will need to activate your license.
